Structural Engineer in Houston Heights, TX

Is your address inside a historic district?

This is the first question to answer, before an architect draws anything, because in much of the Heights the answer is yes and it changes what is possible.

Work on a contributing structure inside a City of Houston historic district needs a Certificate of Appropriateness from the Houston Archaeological and Historical Commission, and that review is separate from and additional to the building permit. It looks at what the change does to the street: height, massing, proportion, and whether the addition reads as part of the original house or as something dropped on top of it.

For second stories specifically the guidelines get concrete. The commission looks at whether the proportions of the new upper floor relate to the floor below and to the surrounding block, and in a context of entirely single-story contributing houses, a second story faces a much harder road. We have seen designs that were structurally straightforward get sent back on massing, and the fix cost more in schedule than it did in engineering.

The practical order is: find out your district status, get the structural evaluation, then design to both constraints at once. Designing first and discovering the constraints second is how Heights projects lose a season.

Pier and beam, not slab, and why that changes everything

Most of Houston is slab on grade. The Heights largely is not. The bungalows here were built on pier and beam, with a crawl space underneath, and that is a completely different structural conversation from the one we have in Katy or Cypress.

The good news is access. We can get under a pier and beam house and actually look at the floor framing, the sills, the beams and the piers, which on a slab house we can only infer from measurements taken above. When a Heights floor slopes or bounces, we can usually tell you exactly why.

What we find is usually some combination of the same things: original piers that have settled unevenly or were never founded deep enough for this soil, beams and sill plates with rot where they have sat close to damp ground for ninety years, floor joists that were adequate for 1920 loads and are undersized for a modern kitchen with stone counters and a large island, and previous repairs done with concrete blocks stacked without mortar.

None of that is unusual and none of it is alarming on its own. It does mean that a Heights renovation almost always includes foundation work, and that budgeting a Heights project without getting under the house first is guessing.

Putting a second story on a bungalow

A 1920s Heights bungalow was built to carry one floor and a roof, on piers sized for that load. Adding a full second story roughly doubles what the structure below has to carry, and the load has to reach the ground through a path that in many of these houses does not currently exist as a continuous line.

In practice that means three things get looked at. The piers and their footings, which usually need to be supplemented or replaced with properly founded ones. The floor framing and the beams, which have to carry both the new upper floor and the walls holding it up. And the walls themselves, because a load-bearing wall on the ground floor needs something solid underneath it, not a joist span.

This is doable and we do it. What we will not do is tell you it is simple. A second story on a Heights bungalow is a foundation and framing project with a new floor on top, and the honest budget reflects that. The process is described in more detail on the second story addition page.

Opening up a bungalow floor plan

The other constant request here is taking out the wall between the front room and the kitchen. Heights bungalows were built as a series of small separate rooms, and almost nobody wants to live that way now.

On a pier and beam house this is often more straightforward than the same job on a slab, because the beam bears down onto posts that land on new piers we can actually build properly, rather than onto a slab edge that was never designed for a point load. The catch is what is above: many of these houses have had attic conversions, dormers or roof changes over a century, and the load coming down is not always what the original framing plan suggests.

We open the ceiling, look at what is actually bearing, size the beam for that rather than for the drawing, and specify the posts and the piers underneath. More on the process here: load-bearing wall removal.

The ridge, drainage, and what it does and does not protect you from

Being on higher ground genuinely helps. The Heights came through several of the storms that flooded surrounding neighborhoods in better shape, and the elevation is a real part of why.

What the ridge does not do is stop the soil from moving. The clay under the Heights swells and shrinks with moisture like clay everywhere else in this region, and on pier and beam that shows up as uneven pier settlement rather than as a cracked slab. A century-old house has been through a hundred wet and dry cycles, and the piers record all of them.

The thing an owner can control here is the same as everywhere: keep the moisture around the perimeter steady, keep the crawl space ventilated and dry, and keep water moving away from the house rather than pooling against it. On a pier and beam house in particular, a damp crawl space is the start of most of the rot we find.
